CM Camlok TTR Girder Clamp, Working Load Limit 3,300 lbs., Part No. TTR1500

Manufacturer: CM (Columbus McKinnon)

SKU: TTR1500

Manufacturer part number: TTR1500

Lead Time (subject to change, call to verify): typically ships in 7-10 business days

Beam Flange Width

1/4 to 1 in.

$2,339.88

Qty:

Documents, Drawings, and Manuals

Brochure

CM Lifting Clamps Brochure

Product Specifications

Attribute name	Attribute value
Features	Part Number: TTR1500 Working Load Limit (min.): 350 lbs. Working Load Limit (max.): 3,300 lbs. Flange: 1/4 to 1 in. Weight: 22.0 lbs. TTR Clamps can be used on girders and rolled steel joists up to a surface hardness of 300 Brinell (32HRc). These clamps are designed for handling structural beams with the flange in a vertical position, or “H” position. Used to lift and transport structural beams up to a surface hardness of 300 Brinell (32HRc) with the flanges in the upright position. Versatile tool for transporting girders and joists. Can be used to lift and stack girders horizontally. The hook rings are designed to be as near to the center of gravity as possible, resulting in a near horizontal lift. Clamp is fitted with a cam-operated locking mechanism. Short beams may be lifted with a single clamp, longer beams should use 2 clamps in combination with a spreader beam. 4:1 design factor.
