CM Camlok TTG Horizontal Girder Clamp, Working Load Limit 6,600 lbs., Part No. TTG3000

SKU: TTG3000

Manufacturer part number: TTG3000

Lead Time (subject to change, call to verify): typically ships in 7-10 business days

Plate Size

$2,829.71

Qty:

Documents, Drawings, and Manuals

Brochure

CM Lifting Clamps Brochure

Product Specifications

Attribute name	Attribute value
Features	Part Number: TTG3000 Working Load Limit (min.): 350 lbs. Working Load Limit (max.): 6,600 lbs. Plate: 0 to 1-3/8 in. Weight: 24.3 lbs. TTG Clamps are designed to lift and transport structural steel beams in the horizontal position. Designed to lift and transport structural steel beams in the horizontal position. Fitted with a Camlok spring-operated safety lock and is operated by pulling the lock upwards. For short beams, a single clamp can be used. Long beams should be lifted using 2 clamps attached to opposite beam flanges. Maximum hardness of material to lift should not exceed 300 Brinell (32HRc). 4:1 design factor.
